Nguồn gốc:
Được làm ở Trung Quốc
Hàng hiệu:
Belparts
Số mô hình:
DH290LC-V
| Parameter | Value |
|---|---|
| Model | DH290LC-V |
| Category | Hydraulic Motor |
| Part Numbers | 2101-1025G, 2101-1025E, 2101-1025H |
| Place of Origin | Other Country |
| Condition | Original & OEM |
| Warranty | 12 months |
| MOQ | 1 pcs |
| Production Capacity | 1000 pcs/Month |
| Standard | Standard |
| Payment Terms | L/C, T/T, Trade Assurance |
| Delivery Time | 1-3 days (depends on order) |
| Transport | By Sea, Air or DHL |
| No. | Part Number | Description | Weight/Dimensions | Qty |
|---|---|---|---|---|
| - | 2101-1025E | SWING REDUCTION GEAR ASS'Y | 1 | |
| - | 2101-1025G | REDUCTION GEAR ASS'Y | 1 | |
| - | 2101-1025H | REDUCTION GEAR ASS'Y | 1 | |
| - | 2101-1025I | REDUCTION GEAR ASS'Y | 337 kg | 1 |
| 1 | 2423-1184D | CASING, FRONT | 38 kg | 1 |
| 2 | 2423-1185 | CASING, MIDDLE | 31 kg | 1 |
| 3 | 2112-1156C | SHAFT, DRIVE | 52 kg | 1 |
| 3 | 2112-1156E | SHAFT, DRIVE | 43 kg | 1 |
| 4 | 2104-1004C | GEAR, RING(NO.2) | 1 | |
| 4 | 2104-1004E | GEAR, RING(NO.2) | 29 kg / 460*460*90 | 1 |
| 5 | 2101-1006C | GEAR, PLANETARY(NO.2) | 3 | |
| 5 | 2101-1006E | GEAR, PLANETARY(NO.2) | 7 kg | 3 |
| 6 | 2101-1005E | GEAR, SUN(NO.2) | 1 | |
| 6 | 2101-1005G | GEAR, SUN(NO.2) | 6 kg | 1 |
| 6 | 2101-1005H | GEAR, SUN(NO.2) | 6 kg | 1 |
| 7 | 2104-1005C | GEAR, RING(NO.1) | 8 kg | 1 |
| 8 | 2101-1031 | GEAR, PLANETARY(NO.1) | 1 kg | 3 |
| 9 | 2101-1032 | GEAR, SUN(NO.1) | 3 kg | 1 |
| 10 | 2230-1034 | CARRIER | 8 kg | 1 |
| 11 | 2123-1631B | PIN | 2 kg | 3 |
| 12 | 2114-1553 | WASHER, THRUST | 6 | |
| 12 | 2114-1553A | WASHER, THRUST | 6 | |
| 13 | 2549-1118 | BUTTON, THRUST | 1 | |
| 14 | 2123-1632 | PIN(NO.1) | 1 kg | 3 |
| 15 | 2412-9001 | SIDE PLATE NO.1(=2412-9001P) | 12 kg | 3 |
| 16 | 2412-9002 | SIDE PLATE NO.2 | 3 | |
| 17 | 2412-9003 | SIDE PLATE(=2412-9003P) | 1 | |
| 18 | 2505-1009 | BAR, LEVEL | 1 kg | 1 |
| 19 | 2182-1304 | PIPE | 1 | |
| 20 | 2278-1009A | RING, SPACER | 1 kg | 1 |
| 21 | 2123-1634 | PIN, KNOCK | 4 | |
| 22 | 2109-9031 | SPH.ROLLER BRG.(=2109-9031P) | 12 kg | 1 |
| 23 | 2109-9032 | SPH.ROLLER BRG.(=2109-9032P) | 5 kg | 1 |
| 24 | 2216-9001 | NEEDLE CAGE(=2216-9001P) | 3 | |
| 25 | S2225971 | BOLT, LOCK | 1 kg | 16 |
| 26 | S2224871 | LOCK BOLT, REDUCTION GEAR | E0502399 | 12 |
| 27 | 2180-1235 | SEAL, OIL | 1 | |
| 28 | 2123-1633D2 | PIN, SPRING | 3 |
