Nguồn gốc:
Trung Quốc
Hàng hiệu:
Belparts
Chứng nhận:
CE
Số mô hình:
SK210-5 SH210A5 CX210 CX210B
| Application | Excavator |
| Part Name | Hydraulic Pump |
| Machine Model | Kobelco SK210-5 Sumitomo SH210A5 CASE CX210 CX210B |
| Part Number | KRJ10290 KRJ6199 |
| Type | K3V112DTP1F9R-9Y14-HV K3V112DTP-1X5R-9X14-V |
| Warranty | 12 months |
| Delivery Time | 3-7 Days |
| Shipment | Express/freight/sea/train |
| Quality | Made in China OEM / High Quality |
| MOQ | 1 Piece |
| Payment Term | T/T, Trade Assurance, Paypal and etc |
| Category | Construction Machinery Part |
| # | Part No. | Description | Qty |
|---|---|---|---|
| 0 | KRJ10290 | HYDRAULIC PUMP | 1 |
| Include(s) 1 - 110 | |||
| 1 | LJ014510 | HYDRAULIC PUMP | 1 |
| See Figure(s) 08-101-00 01 | |||
| 23 | TJ00765 | PISTON | 2 |
| Include(s) 24, 25 | |||
| 24 | NSS | NOT SOLD SEPARAT | 18 |
| 25 | NSS | NOT SOLD SEPARAT | 18 |
| 26 | LJ014500 | BARREL | 1 |
| Include(s) 27, 28 | |||
| 27 | NSS | NOT SOLD SEPARAT | 1 |
| 28 | NSS | NOT SOLD SEPARAT | 1 |
| 29 | LJ014490 | BARREL | 1 |
| Include(s) 30, 31 | |||
| 30 | NSS | NOT SOLD SEPARAT | 1 |
| 31 | NSS | NOT SOLD SEPARAT | 1 |
| 32 | LR00552 | PLATE | 2 |
| Include(s) 33, 34 | |||
| 33 | NSS | NOT SOLD SEPARAT | 2 |
| 34 | NSS | NOT SOLD SEPARAT | 2 |
| 35 | TNP0022 | VALVE | 2 |
| Include(s) 36 - 38 | |||
| 36 | NSS | NOT SOLD SEPARAT | 2 |
| 37 | NSS | NOT SOLD SEPARAT | 2 |
| 38 | NSS | NOT SOLD SEPARAT | 2 |
| 39 | TNP0023 | VALVE | 2 |
| Include(s) 40 - 42 | |||
| 40 | NSS | NOT SOLD SEPARAT | 2 |
| 41 | NSS | NOT SOLD SEPARAT | 2 |
| 42 | NSS | NOT SOLD SEPARAT | 2 |
| 43 | LJ014460 | VALVE SECTION | 1 |
| See Figure(s) 08-102-00 01 | |||
| 62 | 160161A1 | LEVER ASSY. | 2 |
| Include(s) 63, 64 | |||
| 63 | NSS | NOT SOLD SEPARAT | 1 |
| 64 | NSS | NOT SOLD SEPARAT | 1 |
| 65 | 160033A1 | DRIVE SHAFT | 1 |
| 66 | 160034A1 | DRIVE SHAFT | 1 |
| 67 | LB00535 | COUPLING | 1 |
| 68 | TB00026 | BEARING, ROLLER, CYL,40mm ID x 90mm OD x 23mm W | 2 |
| 69 | TB00082 | NEEDLE BEARING,35 mm ID x 47 mm OD x 30 mm | 2 |
| 70 | 156963A1 | SPACER | 4 |
| 71 | TR00047 | PLATE | 2 |
| 72 | 169288A1 | BUSHING | 2 |
| 73 | 156960A1 | SPRING | 18 |
| 74 | 160113A1 | PLATE | 2 |
| 75 | TPP0080 | SUPPORT | 2 |
| 76 | 160334A1 | COVER | 1 |
| 77 | LJ014520 | HYDRAULIC PUMP | 2 |
| 78 | TJ00067 | VALVE BLOCK | 1 |
| 79 | NSS | NOT SOLD SEPARAT | 1 |
| 80 | 167078A1 | BOLT,M8 x 40mm, Cl 12.9 | 8 |
| 81 | 861-8020 | HEX SOC SCREW,M8 x 20mm, Cl 12.9 | 4 |
| 82 | 863-10020 | HEX SOC SCREW,M10 x 20mm, Cl 12.9 | 4 |
| 83 | 155496A1 | PLUG | 2 |
| 84 | TLM0023 | PLUG | 2 |
| 85 | 155471A1 | PLUG | 4 |
| 86 | LK00003 | PLUG | 27 |
| 87 | TJ00066 | PISTON | 2 |
| 88 | TG00286 | STOP LOCK | 2 |
| 89 | 161116A1 | COVER | 2 |
| 90 | 154553A1 | O-RING | 2 |
| 91 | LE013510 | O-RING | 2 |
| 92 | LE013500 | O-RING | 4 |
| 93 | LE013470 | O-RING | 16 |
| 94 | LE013410 | O-RING | 6 |
| 95 | LE013490 | O-RING | 2 |
| 96 | LE013440 | O-RING | 4 |
| 97 | 154489A1 | O-RING | 2 |
| 98 | LE018730 | OIL SEAL | 1 |
| 99 | 153970A1 | BACK-UP RING | 2 |
| 100 | 154017A1 | BACK-UP RING | 2 |
| 101 | 164R016VR | NUT | 2 |
| 102 | 829-1420 | NUT,M20, Cl 10 | 2 |
| 103 | 800-1140 | SNAP RING,M40, Ext | 2 |
| 104 | 156954A1 | DOWEL | 2 |
| 105 | 338W060Z014B | LINCH PIN | 4 |
| 106 | 126R010SR | EYEBOLT; BOLT, EYE | 2 |
| 107 | LA00036 | SET SCREW,Hex | 2 |
| 108 | 160296A1 | SET SCREW | 2 |
| 109 | LL001680 | REGULATOR | 1 |
| See Figure(s) 08-103-00 01 | |||
| 110 | LL001670 | REGULATOR | 1 |
| See Figure(s) 08-104-00 01 | |||
Belparts have a large workshop for excavator parts producing, from material cutting, welding, heating treating, assembling, debugging, painting, testing, every part we will confirm before leaving the factory.
